standard length
chart
| Rope Dia | Minimum (mtr/Yard) | Minimum (Feet) | Maximum (mtr/Yard) | Maximum (Feet) |
|---|---|---|---|---|
| 2mm | 50 | 150 | 2000 | 6000 |
| 3mm | 50 | 150 | 2000 | 6000 |
| 4mm | 50 | 150 | 500 | 1500 |
| 5mm | 50 | 150 | 2000 | 6000 |
| 6mm | 50 | 150 | 2000 | 6000 |
| 7mm | 50 | 150 | 1500 | 4500 |
| 8mm | 50 | 150 | 1500 | 4500 |
| 9mm | 50 | 150 | 1000 | 3000 |
| 10mm | 50 | 150 | 500 | 1500 |
| 12mm | 50 | 150 | 500 | 1500 |
| 14mm | 50 | 150 | 500 | 1500 |
| 16mm | 50 | 150 | 500 | 1500 |
| 18mm | 50 | 150 | 300 | 900 |
| 20mm | 50 | 150 | 200 | 600 |
| 22mm | 50 | 150 | 200 | 600 |
| 24-60mm | 50 | 150 | 100 | 300 |
| DIA (MM) | DIA (INCH) | CIR (INCH) | KG/220 METER | LBS/220 METER | KG/100 METER | LBS/100 METER | MBL (Lbs) | MBL (Kgs) |
|---|---|---|---|---|---|---|---|---|
| 2 | 2/25 | 1/4 | 0.44 | 0.968 | 0.20 | 0.44 | 193 | 88kgf |
| 3 | 3/25 | 3/8 | 0.84 | 1.848 | 0.38 | 0.84 | 330 | 150kgf |
| 4 | 5/32 | 1/2 | 1.32 | 2.904 | 0.60 | 1.32 | 473 | 215 kgf |
| 5 | 3/16 | 5/8 | 2.45 | 5.39 | 1.11 | 2.44 | 704 | 320 kgf |
| 6 | 7/32 | 3/4 | 3.74 | 8.228 | 1.70 | 3.74 | 1320 | 600 kgf |
| 7 | 1/4 | 7/8 | 5.1 | 11.22 | 2.32 | 5.10 | 1650 | 750 kgf |
| 8 | 5/16 | 1 | 6.6 | 14.52 | 3 | 6.60 | 2332 | 1060 kgf |
| 9 | 11/32 | 1-1/8 | 8.1 | 17.82 | 3.68 | 8.10 | 2618 | 1190 kgf |
| 10 | 3/8 | 1-1/4 | 9.9 | 21.78 | 4.5 | 9.90 | 3432 | 1560 kgf |
| 12 | 1/2 | 1-1/2 | 14.3 | 31.46 | 6.5 | 14.30 | 4862 | 2210 kgf |
| 14 | 9/16 | 1-3/4 | 20 | 44 | 9.09 | 20.00 | 6710 | 3050 kgf |
| 16 | 5/8 | 2 | 25.3 | 55.66 | 11.5 | 25.30 | 8316 | 3.78 Ts |
| 18 | 3/4 | 2-1/4 | 32.5 | 71.5 | 14.77 | 32.49 | 10604 | 4.82 Ts |
| 20 | 13/16 | 2-1/2 | 40 | 88 | 18.18 | 40.00 | 12760 | 5.80 Ts |
| 22 | 7/8 | 2-3/4 | 48.4 | 106.48 | 22 | 48.40 | 15312 | 6.96 Ts |
| 24 | 1 | 3 | 57 | 125.4 | 25.91 | 57.00 | 17864 | 8.13 Ts |
| 26 | 1-1/16 | 3-1/4 | 67 | 147.4 | 30.45 | 66.99 | 20702 | 9.41 Ts |
| 28 | 1-1/8 | 3-1/2 | 78 | 171.6 | 35.45 | 77.99 | 23540 | 10.70 Ts |
| 30 | 1-1/4 | 3-3/4 | 89 | 195.8 | 40.45 | 88.99 | 26884 | 12.22 Ts |
| 32 | 1-5/16 | 4 | 101 | 222.2 | 45.91 | 101.00 | 29700 | 13.50 Ts |
| 34 | 1-3/8 | 4-1/4 | 115 | 253 | 52.27 | 114.99 | 31680 | 14.40 Ts |
| 36 | 1-7/16 | 4-1/2 | 129 | 283.8 | 58.64 | 129.01 | 37246 | 16.93 Ts |
| 38 | 1-9/16 | 4-3/4 | 142 | 312.4 | 64.55 | 142.01 | 38940 | 17.70 Ts |
| 40 | 1-5/8 | 5 | 158 | 347.6 | 71.82 | 158.00 | 45122 | 20.51 Ts |
| 42 | 1-11/16 | 5-1/4 | 176 | 387.2 | 80 | 176.00 | 47080 | 21.40 Ts |
| 44 | 1-3/4 | 5-1/2 | 194 | 426.8 | 88.18 | 194.00 | 54208 | 24.64 Ts |
| 46 | 1-7/8 | 5-3/4 | 211 | 464.2 | 95.81 | 210.78 | 55660 | 25.30 Ts |
| 48 | 1-15/16 | 6 | 229 | 503.8 | 104.09 | 229.00 | 62942 | 28.61 Ts |
| 50 | 2 | 6-1/4 | 248 | 545.6 | 112.73 | 248.01 | 64460 | 29.30 Ts |
| 52 | 2-1/8 | 6-1/2 | 268 | 589.6 | 121.82 | 268.00 | 72842 | 33.11 Ts |
| 54 | 2-3/16 | 6-3/4 | 290 | 638 | 131.82 | 290.00 | 74140 | 33.70 Ts |
| 56 | 2-1/4 | 7 | 312 | 686.4 | 141.82 | 312.00 | 83292 | 37.86 Ts |
| 58 | 2-5/16 | 7-1/4 | 335 | 737 | 152.27 | 334.99 | 84920 | 38.60 Ts |
| 60 | 2-3/8 | 7-1/2 | 359 | 789.8 | 163.18 | 359.00 | 95238 | 43.29 Ts |
| DIA (MM) | DIA (INCH) | CIR (INCH) | KG/220 METER | LBS/220 METER | KG/110 METER | LBS/110 METER | MBL (LBS) | MBL (KG) |
|---|---|---|---|---|---|---|---|---|
| 24 | 1 | 3 | 53.00 | 116.60 | 26.50 | 58.30 | 17866 | 8.13 Ts |
| 28 | 1-1/8 | 3-1/2 | 72.50 | 159.50 | 36.25 | 79.75 | 23540 | 10.70 Ts |
| 32 | 1-5/16 | 4 | 94.00 | 206.80 | 47.00 | 103.40 | 29700 | 13.50 Ts |
| 36 | 1-7/16 | 4-1/2 | 120.00 | 264.00 | 60.00 | 132.00 | 37246 | 16.93 Ts |
| 40 | 1-5/8 | 5 | 147.00 | 323.40 | 73.50 | 161.70 | 45122 | 20.51 Ts |
| 44 | 1-3/4 | 5-1/2 | 180.50 | 397.10 | 90.25 | 198.55 | 54208 | 24.64 Ts |
| 48 | 1-15/16 | 6 | 213.00 | 468.60 | 106.50 | 234.30 | 62942 | 28.61 Ts |
| 52 | 2-1/16 | 6-1/2 | 250.00 | 550.00 | 125.00 | 275.00 | 72842 | 33.11 Ts |
| 56 | 2-1/4 | 7 | 290.00 | 638.00 | 145.00 | 319.00 | 83270 | 37.85 Ts |
| 60 | 2-3/8 | 7-1/2 | 334.00 | 734.80 | 167.00 | 367.40 | 95216 | 43.28 Ts |
| 64 | 2-1/2 | 8 | 378.50 | 832.70 | 189.25 | 416.35 | 107756 | 48.98 Ts |
| 68 | 2-15/16 | 8-1/2 | 427.00 | 939.40 | 213.50 | 469.70 | 121528 | 55.24 Ts |
| 72 | 2-7/8 | 9 | 479.00 | 1053.80 | 239.50 | 526.90 | 135300 | 61.50 Ts |
| 76 | 3 | 9-1/2 | 534.00 | 1174.80 | 267.00 | 587.40 | 150854 | 68.57 Ts |
| 80 | 3-1/4 | 10 | 593.00 | 1304.60 | 296.50 | 652.30 | 166408 | 75.64 Ts |
| 84 | 3-1/2 | 10-1/2 | 654.00 | 1438.80 | 327.00 | 719.40 | 183040 | 83.20 Ts |
| 88 | 3-15/16 | 11 | 718.00 | 1579.60 | 359.00 | 789.80 | 199672 | 90.76 Ts |
| 92 | 3-7/8 | 11-1/2 | 787.00 | 1731.40 | 393.50 | 865.70 | 217690 | 98.95 Ts |
| 96 | 3-3/4 | 12 | 852.00 | 1874.40 | 426.00 | 937.20 | 243562 | 110.71 Ts |
| 100 | 4 | 12-1/2 | 930.00 | 2046.00 | 465.00 | 1023.00 | 256300 | 116.50 Ts |
| 104 | 4-1/2 | 13 | 1005.00 | 2211.00 | 502.50 | 1105.50 | 277640 | 126.20 Ts |
| 108 | 4-15/16 | 13-1/2 | 1084.00 | 2384.80 | 542.00 | 1192.40 | 291280 | 132.40 Ts |
| 112 | 4-7/8 | 14 | 1060.00 | 2332.00 | 530.00 | 1166.00 | 308000 | 140.00 Ts |
| 116 | 4-3/4 | 14-1/2 | 1051.00 | 2312.20 | 525.00 | 1155.00 | 326700 | 148.50 Ts |
| 120 | 5 | 15 | 1065.00 | 2343.00 | 532.50 | 1171.50 | 343860 | 156.30 Ts |
